技術(shù)數(shù)據(jù)
|
S/N |
Item |
Parameters |
|
|
1 |
Center Frequency(F0) |
22GHz |
|
|
2 |
3.0dB Bandwidth |
1.25GHz Max. (21.375 ~ 22.625GHz Max.) |
|
|
3 |
1.0dB Pass Band Bandwidth |
1.0GHz (21.5 ~ 22.5GHz) |
|
|
4 |
Pass Band Insertion Loss |
≤2.0dB @ 21.5 ~ 22.5GHz |
|
|
5 |
Pass Band Ripple |
≤1.0dB @ 21.5 ~ 22.5GHz |
|
|
6 |
Pass Band VSWR |
≤1.3:1 @ 21.5 ~ 22.5GHz |
|
|
7 |
Stop Band Rejection |
≥70dB @ F0±1.1GHz (DC ~ 20.9GHz , 23.1 ~ 40GHz) |
|
|
8 |
Impedance |
50 Ohms |
|
|
9 |
Power Handling |
5W Max. |
|
|
10 |
Connectors |
SMA-Female |
|
|
11 |
Surface Finish |
Painted Black |
|
|
12 |
Temperature Range |
-30℃ ~ +70℃ |
|
|
13 |
Material |
Housing: H62 Copper alloy Cover: H62 Copper alloy Tuning screw: H62 Copper alloy |
Connectors: Stainless Steel Other screw: Stainless Steel |
|
14 |
Dimensions |
70*16*9mm |
|
|
15 |
Net weight |
0.075 KG |
|
