技術數據
|
S/N |
Item |
Parameters |
|
|
1 |
Center Frequency(F0) |
37GHz |
|
|
2 |
Pass Band Bandwidth |
100MHz (36.95 ~ 37.05GHz) |
|
|
3 |
Pass Band Insertion Loss |
≤1.7dB |
|
|
4 |
Pass Band Return Loss |
≥15dB (Input / Output) |
|
|
5 |
Stop Band Attenuation |
≥40dB @ DC ~ 36GHz |
≥40dB @ 38 ~ 48GHz |
|
6 |
Impedance |
50 Ohms |
|
|
7 |
Power Handling |
5W Max. |
|
|
8 |
Connectors |
Input: 2.92mm(K)-Female / Output: 2.92mm(K)-Male |
|
|
9 |
Surface Finish |
Painted Black |
|
|
10 |
Temperature Range |
-30℃ ~ +70℃ |
|
|
11 |
Material |
Housing: H62 Copper alloy Cover: H62 Copper alloy Tuning screw: H62 Copper alloy |
Connectors: Stainless Steel Other screw: Stainless Steel |
|
12 |
Dimensions |
40*16*7.5mm |
|
|
13 |
Net weight |
0.04 KG |
|
